14.00$
Report AbuseDescription
Model No XD – C301 ( for car ADAS system )
Imaging device 1/2.9 2M Pixel CMOS
Pixels 1080P/25fps 1080P/30fps
Video output AHD 1.0Vp-p/75Ω
Minimum illumination 0.01Lux
SNR >50dB
Lens 6mm F2.0
Lens angle 600 H 300V
Electronic shutter AUTO: 1/50sec 1/60sec
White balance AUTO
Gamma correction 0.45
Night vision effect Color pictures
Interface 4-pin air connector
Cable length 2m
Voltage DC 9 – 16V
Current 240mA@12V
Temperature range -300 ～ 850
IP code IP54
