Mobile DVR with BSD System Model No A5S – lite – 2

Mobile DVR with BSD System Model No A5S – lite – 2

Mobile DVR with BSD System Model No A5S – lite - 2
Mobile DVR with BSD System Model No A5S – lite - 2 - Image 2
Mobile DVR with BSD System Model No A5S – lite - 2 - Image 3
Mobile DVR with BSD System Model No A5S – lite - 2 - Image 4

220.00$

Features:
 A compact model car DVR with embedded BSD system which alerts the
driver whenever it detects pedestrians, non-motorized vehicles or other
obstacles in the blind spot area around your vehicle
 GPS+BDS positioning & tracking
 High definition videos
 Candid photography
 BSD camera
 Sound and light alarm siren
 7’ bus monitor
 The system will transfer a signal and run into sleep mode when the
vehicle breaks down
 Size: 160 x 140 x 48mm
 Recommended for use in such vehicles as passenger buses, heavy duty
trucks, engineering vehicles, etc.

x
Category:
Report Abuse

Description

Technical Specifications

Video Input 4 CH AHD 1080P/720P
Video Encoding
H.265/H.264 dual stream coding
candid photography supported
Audio 1 CH input G.726 audio encoding 1 CH output
Video Output 1 CH CVBS 1CH VGA
Satellite Positioning
GPS + BD2 warm start ≤ 1s cold start ≤ 38s
positioning accuracy ≤ 2.5m
speed accuracy ≤ 0.1m/s
Storage 1 x SD card ( 32G/64G/128G/256G )
G-Sensor 3-axis accelerometer and 6-axis gyroscope
Interfaces
USB 2.0 x 1 RS232 x1
1 x RS232/RS485 available for option on the rear panel
Power Input DC 9～36V
Power Output 12V 5V
Indicator Lights
Power platform positioning
video storage alarm etc.
Temperature Range -30～80℃ ( operation ) -40～85℃ ( storage )
Relative Humidity 93%
Dimensions 140 x 118 x 35mm

  • Miniaturized Mobile DVR ( ADAS + DMS )

    Technical Specifications

    System Linux 3.10
    Video In 4 CH AHD 1080P/720P + 1 CH IPC
    Video Coding  H.265/H.264
    Audio In 4 CH VoIP supported
    Video/Audio Out 1 CH ( CVBS )
    Positioning GPS + BD2 dual positional modules
    Wireless Communication 4G   embedded WiFi module
    Face ID & DMS

     ( optional )

    		 Voice messages reminding you of drowsiness ( closing eyes, sighing ), smoking, making calls, driver absent, etc.
    ADAS ( optional ) Warnings against front collision, lane departure or being close to other cars
    Storage T-Flash card 256G x 2
    Interface USB x 1  A/D converter x 2  RS232 x 1

    RS485 x 1  CAN x 1
    Gravity Sensor 3-axis
    Power AC/DC 9 – 36V
    Temperature Range -25～75℃ ( operation )
    Moisture 10% – 95% RH
    Dimensions 90 x 90 x 30mm
    NWT 295g ( host processor )

    Original price was: 139.00$.Current price is: 119.00$.
  • 5A Fast Charging 3 in 1 Cable

    Output: 5A
    Function: Charging (Only USB C Support data transfer)
    Length: 1.25m

    1.40$
  • N52 Magnetic Phone Holder 360 Rotation Adjustable Air Vent Phone holder Car Mount
    3.30$ - 3.70$
  • Car Black Box / Mobile DVR M6

    Features:

    High definition video channels with an IP camera
    GPS + BDS dual positioning modules
    WiFi-AP 3G/4G LTE telecommunication
    CAN bus connection ( ignition, speed, brake, lights, motor rotations, fuel consumption, etc. )
    A peripheral rugged data memory device that survives 11000C high temperature fire and functions 100m underwater for 240 hours
    For surveillance, tracking and fleet management online when connected to our platform
    A versatile telematics device for security and safety of passenger buses, heavy duty trucks or oil tankers.
    Size：138 x 170 x 66mm

    NWT：1000g

    250.00$
  • ADAS Camera Model No XD-C301

    Model No XD – C301 ( for car ADAS system ) Imaging device 1/2.9 2M Pixel CMOS Pixels 1080P/25fps 1080P/30fps Video output AHD 1.0Vp-p/75Ω Minimum illumination 0.01Lux SNR >50dB Lens 6mm F2.0 Lens angle 600 H 300V Electronic shutter AUTO: 1/50sec 1/60sec White balance AUTO Gamma correction 0.45 Night vision effect Color pictures Interface 4-pin […]

    14.00$
  • Reinforced Refractory Data Memory Module TR – P Model

    Features:
     A rugged data memory module for
    protection of data in extreme conditions.
     air connector
     Storage via eMMC or SSD
     Proof against 1100℃ high intensity fire
     antishock and waterproof
     Stored data immediately accessible in case
    of harsh events such as fire, explosion,
    hard crash or water immersion, and thus
    facilitating immediate further analysis and
    investigations of the events
     Recommended for use in rail transit
    vehicles, oil tank trailers and heavy-duty
    trucks.
     As per international railway equipment
    quality standard: IEC62625.1 2013
     Size: 92 x 80 x 48mm
     NWT: 1.3kg

    899.00$

Product Enquiry

Related products

  • Mobile Tracking Solution of Muck Trucks

    The tracking solution is designed to enhance the safety, security and operational efficiency of muck truck fleet on the way. It enables you to access the real-time data, alerts and reports from the fleet of muck trucks throughout all the routes. The cameras, sensors and the fleet management software help reduce your labor and increase […]

    220.00$
  • Refractory Car Data Memory QF-AU Model

    Features:
     A fireproof model of memory device for use in
    in extremely tough conditions
     Auxiliary data memory device connected to car
    DVRs, monitoring equipment or other security
    devices
     Air connector M12-5PIN
     Resistant to 1100℃high temperature fire
     Survivable at 100m deep water for 240 hours
     Stored data retrievable immediately after
    incidents of fire, explosion, immersion, car
    crash, etc.
     Size: 122 x 88 x 57mm
     NWT: 1kg

    899.00$
  • 4CH H.265 WiFi NVR SECURITY SYSTEM OEM-N3

    660.00$
  • Outdoor Battery Camera( 2MP ）



    33.70$ - 40.25$
