119.00$
You save
Features:
High definition videos
GPS + BDS dual positioning modules
4G and WiFi are available for your option
Both video files and video streaming may be encrypted for protection
of your data information
Alarms for such events as overspeeding, overtime temporary parking
and continuous driving for over 4 hours.
Two emergency buttons are available for you to contact the online
management in case of emergency.
Mileage calculator
Description
Technical Specifications
System Linux
Video Input 4 CH 1080P AHD 2.0
Video Output 2 CH: VGA + CVBS with blind spot monitoring
Video Compression H.264/H.265 high profile
Audio
Input: 4 embedded audios on cameras. You could choose only one
channel at a time for operation.
Output: 1 CH
Audio Compression G.711, G.726
Data Encryption 256bit for both video files and video streaming
Positioning Modules GPS + BD2
Storage SD x 2 ( 256G x 2 )
Wireless Communication
( optional )
3G/4G, WiFi
Interface
6-pin ethernet air connector x 1 ( LAN 10/100Mbps )
RS485 x 1 USB x 1
Power
Input: DC9V～36V
Standby: 0.2A@24V
Peak Current: 0.8A@24V
Temperature Range -30～70℃ ( operation )
Anti-vibration ≤50 m/s2 acceleration speed
Impact Acceleration 490 m/s2 11ms
Dimensions 140 x 118 x 35mm
-
Refractory Car Data Memory QF-AU ModelFeatures:
A fireproof model of memory device for use in
in extremely tough conditions
Auxiliary data memory device connected to car
DVRs, monitoring equipment or other security
devices
Air connector M12-5PIN
Resistant to 1100℃high temperature fire
Survivable at 100m deep water for 240 hours
Stored data retrievable immediately after
incidents of fire, explosion, immersion, car
crash, etc.
Size: 122 x 88 x 57mm
NWT: 1kg899.00$ -
