$165.00
You save
Features:
- A fully waterproof mobile DVR for fleet tracking, surveillance and management online
- GPS/BDS dual positioning modules
- 4 video channels AHD 1080P/720P
- 3G/4G wireless transmission
- Compliant with ingress protection standard IP66
- Size：136 x 180 x 50mm
- NWT：1000g
Description
Technical Specifications:
| System | Linux 3.10 |
| Language | Chinese English |
| Video Input | 4 CH AHD 1080P/720P |
| Video Output | 1 CH CVBS |
| Video Display in pixels | PAL: 704 x 576 NTSC: 704 x 480 |
| Video Compression | H.264 |
| Audio | 4 CH input 1 CH output |
| Playback | Single channel ( local ) 1/4/8 CH ( PC software ) |
| Storage | 2 x SD(256G) |
| Wireless Communication | 3G EVDO/WCDMA/TD-SCDMA
4G TD-LTE/FDD-LTE |
| Peripheral Interface | VOIP SIM/UIM card x 1 CAN2.0B x 1
RS485 x 1 RS232 x 1 I/O: Input x 4 Output x 1 |
| Power | Input: DC8V～36V |
| Temperature Range | -25～70℃ ( operation ) |
| Operation Moisture | 10～95% |
| Shell Protection | IP66 |
Vendor Information
- No ratings found yet!
-
Passenger Bus DVR Recording & Surveillance SystemFeatures:
Locating and tracking real routes of buses on the way
Two cameras inside the bus monitoring passengers and real time
events. 30Blind spot detection or 3600 bird’s eye view camera
system that presents a real-time panoramic view of
pedestrians or obstacles surrounding your bus.
Off-route alerts and driver panic buttons.
Face ID and DMS system monitoring driver’s behavior &
minimizing possible risks or dangers during your
journey.
ADAS system that helps avoid dangerous operations
and enhancing the security and safety of your driving.$220.00 -
Refractory Data Memory Module QM – C ModelFeatures:
A state-of-the-art fireproof model of memory
device for use in extremely harsh and tough
conditions
An embedded or peripheral refractory module
of data memories for trains or car recording
systems, bus monitors ( DVR ) or other security
products protecting your data in case of
emergency or in accidents
FPC connector that may be connected to USB
via an adaptor
Storage via eMMC or SSD that can be
converted into USB standard via an adapter
As refractory as a flight data recorder against
1100℃ high temperature fire
Survivable at 100m deep water for 240 hours
Shell made from 6mm alloy steel
As per international standard of railway
equipment ( on board driving data recording
system ): IEC62625.1 2013 with related thirdparty verifications and test reports
Size: 95 x 80 x 48 (mm)
NWT: 1.3kg$998.00 -
Car DVR with Embedded ADAS + DMS Systems Model No A5S-lite-1Intelligent solutions for smart driving and fleet safety Smart Versatile Hybrid DVR The versatile DVR embodies multiple functions with artificial intelligence for tracking and real-time detection of your car performance. Face Identification ( Face ID ) The system captures human faces and compares them against those that have been preserved in file to determine whether […]
$13.00 -
Car Black Box with Embedded ADAS Solutions X505Versatile DVR with Rugged Memory Device
The car black box has 4 video channels for tracking and real-time detection of your car operation. The rugged fireproof memory device survives 1100℃ high intensity fire and enables you to access your data in harsh conditions like fire, water immersion or hard crash.
Face Identification
The system captures human faces and compares them against those that have been preserved in file to determine whether they match with each other. This helps to prevent unauthorized drivers from driving vehicles.
Front Vision Detection
To decrease avoidable crashes and to minimize accidents, the ADAS + system will notify you of a pedestrian or a cyclist in the danger zone and alert you of any possibly imminent crashes. When you are veering off the current travel lane without a lane change signal, it will trigger spoken warnings.
Blind Spot Monitoring
When you signal a turn and shift lanes, the blind spot monitoring system will alert you of a vehicle or other objects nearby but that may be out of your sight.
Driver Behavior Analysis
You will hear a warning whenever our system detects any of your behaviors that are deemed abnormal or unsafe such as talking on the phone, smoking, shielding a camera, fatigue, drowsiness, etc.
A Variety of Recommended Applications
We recommend the use of this intelligent car black box for fleet surveillance and management of public buses, school buses, oil tankers, coaches, vans or other commercial vehicles.
$490.00 -
7’ LCD Video Monitor MFM701Model No MFM701 Screen size 7 inch Resolution 1024 x 600 Luminance 500 cd/m2 Contrast ratio 500 : 1 Aspect ratio 16 : 9 Video format VGA Viewing angle 800 LCD use life 20000 hours Interface 4 pin air connector Power 7W Voltage DC9 – 36V Operation temperature -20～50℃ Storage temperature -30～70℃ Dimensions 173 x […]
$220.00 -
In-car Monitoring Dome Camera XD – C212Technical Specifications
Model No XD – C212 ( in-car monitoring ) Imaging device 1/2.9 1M Pixel CMOS Pixels 720P/1080P/25fps 720P/1080P/30fps Video output AHD 1.0Vp-p/75Ω Minimum illumination 0.01Lux while IR in operation IR range 3 – 6 m SNR >50dB Lens 2.8mm F2.0 Lens angle 950 H 600V Electronic shutter AUTO: 1/50sec 1/60sec White balance AUTO Gamma correction 0.45 Image coloring Color, Black and white while IR in operation Mirror effect Available Interface 4-pin air connector Cable length 0.5m Voltage DC 9 – 16V Current 240mA@12V Temperature range -300 ～ 850 Moisture ≤95% IP code IP54 Original price was: $17.00.$15.00Current price is: $15.00.
