Car Black Box with Embedded ADAS Solutions X505

Car Black Box with Embedded ADAS Solutions X505

$490.00
You save

Versatile DVR with Rugged Memory Device

The car black box has 4 video channels for tracking and real-time detection of your car operation. The rugged fireproof memory device survives 1100℃ high intensity fire and enables you to access your data in harsh conditions like fire, water immersion or hard crash.

Face Identification

The system captures human faces and compares them against those that have been preserved in file to determine whether they match with each other. This helps to prevent unauthorized drivers from driving vehicles.

Front Vision Detection

To decrease avoidable crashes and to minimize accidents, the ADAS + system will notify you of a pedestrian or a cyclist in the danger zone and alert you of any possibly imminent crashes. When you are veering off the current travel lane without a lane change signal, it will trigger spoken warnings.

Blind Spot Monitoring

When you signal a turn and shift lanes, the blind spot monitoring system will alert you of a vehicle or other objects nearby but that may be out of your sight.

Driver Behavior Analysis

You will hear a warning whenever our system detects any of your behaviors that are deemed abnormal or unsafe such as talking on the phone, smoking, shielding a camera, fatigue, drowsiness, etc.

A Variety of Recommended Applications

We recommend the use of this intelligent car black box for fleet surveillance and management of public buses, school buses, oil tankers, coaches, vans or other commercial vehicles.

Quantity Discount (%) Price
100 $490.00
101+ $490.00

Total

x
Report Abuse

Description

commercial vehicles.



Technical Specifications

Video Input 4 CH AHD 1080P/720P
Video Output HDMI x 1
Intercom VOIP x 1
Localization Embedded GPS/BDS modules
Alert Via Sound, Light or Bluetooth peripherals
Interface USB3.0 x 1   CAN x 3   RS232 x 1    RS485 x1
AI Functions ADAS    Face Identification

Driver Behavior Analysis

Wireless Communication 3G/4G  WiFi  Bluetooth 4.1
System Android 7.1
Hardware Platform Qualcomm
Processor Nucleus 8 ARM Cortex A53
CPU Frequency 2.0G
GPU Qualcomm® AndrenoTM 509 GPU
RAM 2G
ROM 16G
Storage Media  SD x 1  max 256GB
Power Input DC8~36V
Power Consumption 5W
Temperature Range -30~75℃
Parameters of crashworthy memory device ( a patented product for option )
Fire Resistance 1100℃/15min   950℃/20min   260℃/120min
Water Immersion 100m underwater   240 hours
Impact Force 50g  100ms ( all axes )



Loading...

Vendor Information

  • No ratings found yet!
  • Car DVR Model No MF4HT

    Features:

    A telematics device for security and safety of passenger buses, school buses, heavy duty trucks or other road vehicles.
    High definition video channels with an IP camera
    GPS + BDS dual positioning modules
    WiFi-AP 3G/4G LTE telecommunication
    Storage via SD card and hard disk
    For surveillance, tracking and fleet management online
    when connected to our platform
    Size:162 x 153 x 52mm

    $213.00
  • Waterproof Car DVR D5

    Features:

    • A fully waterproof mobile DVR for fleet tracking, surveillance and management online
    • GPS/BDS dual positioning modules
    • 4 video channels AHD 1080P/720P
    • 3G/4G wireless transmission
    • Compliant with ingress protection standard IP66
    • Size:136 x 180 x 50mm
    • NWT:1000g



    $165.00
  • Passenger Bus DVR Recording & Surveillance System

    Features:
     Locating and tracking real routes of buses on the way
     Two cameras inside the bus monitoring passengers and real time
    events. 30

    Blind spot detection or 3600 bird’s eye view camera
    system that presents a real-time panoramic view of
    pedestrians or obstacles surrounding your bus.
    Off-route alerts and driver panic buttons.
    Face ID and DMS system monitoring driver’s behavior &
    minimizing possible risks or dangers during your
    journey.
    ADAS system that helps avoid dangerous operations
    and enhancing the security and safety of your driving.

    $220.00
  • Car DVR with Embedded ADAS + DMS Systems Model No A5S-lite-1

    Intelligent solutions for smart driving and fleet safety Smart Versatile Hybrid DVR The versatile DVR embodies multiple functions with artificial intelligence for tracking and real-time detection of your car performance. Face Identification ( Face ID ) The system captures human faces and compares them against those that have been preserved in file to determine whether […]

    $13.00
  • Miniaturized Mobile DVR ( ADAS + DMS )

    Technical Specifications

    System Linux 3.10
    Video In 4 CH AHD 1080P/720P + 1 CH IPC
    Video Coding  H.265/H.264
    Audio In 4 CH VoIP supported
    Video/Audio Out 1 CH ( CVBS )
    Positioning GPS + BD2 dual positional modules
    Wireless Communication 4G   embedded WiFi module
    Face ID & DMS

     ( optional )

    Voice messages reminding you of drowsiness ( closing eyes, sighing ), smoking, making calls, driver absent, etc.
    ADAS ( optional ) Warnings against front collision, lane departure or being close to other cars
    Storage T-Flash card 256G x 2
    Interface USB x 1  A/D converter x 2  RS232 x 1

    RS485 x 1  CAN x 1

    Gravity Sensor 3-axis
    Power AC/DC 9 – 36V
    Temperature Range -25~75℃ ( operation )
    Moisture 10% – 95% RH
    Dimensions 90 x 90 x 30mm
    NWT 295g ( host processor )

    Original price was: $139.00.Current price is: $119.00.
  • In-car Monitoring Video Camera XD – C214

    Technical Specifications



    Model No   XD – C214 ( in-car monitoring )
    Imaging device 1/2.9  1M Pixel CMOS
    Pixels 720P/1080P/25fps   720P/1080P/30fps
    Video output AHD  1.0Vp-p/75Ω
    Minimum illumination 0.001Lux while IR in operation
    IR range 3 – 6 m
    SNR >50dB
    Lens  2.8mm   F2.0
    Lens angle 950 H      600V
    Electronic shutter AUTO:  1/50sec   1/60sec
    White balance AUTO
    Gamma correction 0.45
    Image coloring Color, Black and white while IR in operation
    Mirror effect available
    Interface  4-pin air connector
    Cable length 0.5m
    Voltage DC 9 – 16V
    Current 240mA@12V
    Temperature range -300 ~ 850
    Moisture ≤95%
    IP code IP54

    Original price was: $16.00.Current price is: $13.00.
