Name: Mobile DVR 8CH HDD with ADAS &amp; DMS Systems Model No E5H8H-AI-1
SKU: 8584
Availability: InStock

Mobile DVR 8CH HDD with ADAS & DMS Systems Model No E5H8H-AI-1

Mobile DVR 8CH HDD with ADAS & DMS Systems Model No E5H8H-AI-1 - Image 2

Mobile DVR 8CH HDD with ADAS & DMS Systems Model No E5H8H-AI-1 - Image 3

$222.00

Features

Analog high definition ( AHD ) video channels with an IP camera
Infrared and night vision security cameras may be connected
Snapshot configuration available
GPS+BDS dual positioning modules
4G/ WiFi wireless transmission
Recording modes: continuous/alarm
Storage via TF card and HDD/SSD
DVR malfunctions or system errors recorded and transferred online
A panic button for use in case of emergency
For tracking, surveillance and fleet management online when connected to our platform
Size: 175 x 136 x 70mm

Category: MOBILE DVR Tag: Car DVR

Description

AI Functions

Front Vision Detection and Lane Departure Warning ( ADAS )

To avoid crashes and to minimize accidents, the ADAS system will notify you of any pedestrian or cyclist in the danger zone and alert you of any possibly imminent crashes. When your car deviates from the current lane, or is veering off the current lane without a lane change signal, it triggers audio and visual warnings. The system is highly recommended for the drivers who feel drowsy easily on the road or often spend long hours driving.

Face Identification ( Face ID ) recognizes human faces and helps to prevent unauthorized drivers from driving your cars.

Driver Monitoring System ( DMS ) alerts whenever it detects any of drivers’ behaviors that are deemed abnormal or unsafe. The system sounds audible warnings when the driver is out of sight or whenever it detects any signs of drowsiness or distraction like closing eyes, yawning, smoking, making a phone call, etc.

Integrated Design and Wide Applications

The system integrates DVR with multiple functions like face ID, DMS, BSD and ADAS and is easy to handle. We recommend the use of this intelligent mobile DVR for fleet surveillance and management of public buses, school buses, delivery trucks, oil tankers, coaches, vans or other commercial vehicles.

Customized Configurations

All the above-mentioned AI systems are available for your option dependent on your circumstances. We may integrate one or more of the systems into the DVR as per your request.

Technical Specifications

System	Linux
Video Input	8 CH AHD 1080P@25fps/720P@25fps + 1 IPC
Video Coding	H.265/H.264 high profile dual stream coding
Video output	1 CH D1 + 1 CH VGA
Video connector	CVBS
OSD	Time, car plate No, position, etc. video overlapping
Snapshot	Yes
Audio	A single input from any one of the 8 video inputs G.711, G726 audio stream coding
Positioning	GPS + BDS dual systems, Accuracy: ≤ 2.5m ( position ), ≤ 0.1m/s ( speed )
Wireless communication	4G/3G WiFi ( optional )
Storage	1 x TF ( max 256G ) HDD/SSD ( 1T/2T )
Peripheral Interface	LAN: 10/100<Mbps 6-pin air connector USB x 1 RS485 x 1 I/O: 4 inputs and 1 output
Indicator lights	alarm, video, recording, platform, positioning, power
Power Input	DC9V～36V
Power Output	12V 5V
Temperature Range	-30～70℃ ( operation ) -40～85℃ ( storage )
Humidity	93%
Dimensions	175 x 136 x 70mm
