Features
- Analog high definition ( AHD ) video channels with an IP camera
- Infrared and night vision security cameras may be connected
- Snapshot configuration available
- GPS+BDS dual positioning modules
- 4G/ WiFi wireless transmission
- Recording modes: continuous/alarm
- Storage via TF card and HDD/SSD
- DVR malfunctions or system errors recorded and transferred online
- A panic button for use in case of emergency
- For tracking, surveillance and fleet management online when connected to our platform
- Size: 175 x 136 x 70mm
Description
Technical Specifications
| System | Linux |
| Video Input | 8 CH AHD 1080P@25fps/720P@25fps + 1 IPC |
| Video Coding | H.265/H.264 high profile dual stream coding |
| Video output | 1 CH D1 + 1 CH VGA |
| Video connector | CVBS |
| OSD | Time, car plate No, position, etc. video overlapping |
| Snapshot | Yes |
| Audio | A single input from any one of the 8 video inputs
G.711, G726 audio stream coding |
| Positioning | GPS + BDS dual systems,
Accuracy: ≤ 2.5m ( position ), ≤ 0.1m/s ( speed ) |
| Wireless communication | 4G/3G WiFi ( optional ) |
| Storage | 1 x TF ( max 256G ) HDD/SSD ( 1T/2T ) |
| Peripheral Interface | LAN: 10/100<Mbps 6-pin air connector
USB x 1 RS485 x 1 I/O: 4 inputs and 1 output |
| Indicator lights | alarm, video, recording, platform, positioning, power |
| Power Input | DC9V～36V |
| Power Output | 12V 5V |
| Temperature Range | -30～70℃ ( operation ) -40～85℃ ( storage ) |
| Humidity | 93% |
| Dimensions | 175 x 136 x 70mm |
