Name: Crashworthy Fireproof Data Memory Device TR - C Model for trains and other vehicles
SKU: 8556
Availability: InStock

true 30

$2,692.15

Features:

A rugged crashworthy memory device specially designed for protection of data against extremely harsh events such as fire, explosion, immersion and hard crash.
Withstanding 1100℃ high temperature fire continuously for 60min or 750℃ fire for 60min followed by 600min 260℃ fire.
The stored data can be retrieved immediately after emergency harsh events for relevant analysis and investigations.
Highly suitable for event data recorders of trains, oil tankers, heavy duty trucks, school buses or wherever you have a high demand for protection of your data information in extremely harsh conditions
As per IEEE Standard for Rail Transit Vehicle Event Recorders: IEEE 1482.1 – 2013 and CFR 49 Part 229 Appendix D Option A.
Size: 160 x 110 x 80mm
NWT: 3.8kg

Description

Technical Specifications

Interface Connection	air connector with SATA2.0 or USB2.0 adaptor cable
Power Input	5V±5% <1.5W ( SATA ), <0.5W (USB)
Writing Circulation	SLC: 100000 times MLC: 3000 times
Storage Capacity	eMMC (SLC): □1G □2G □4G □8G
	eMMC (MLC): □16G □32G □64G □128G
	SSD (MLC): □128G □256G □512G □1024G
Fire Resistance	1100℃/60min or 260℃/600min
Fire Resistance	750℃/60min followed by 260℃/600min
Liquid Oil Immersion	48 hours
Water Immersion	100m 240hr
Static Crush	168kN 5min ( 3axes )
Impact Shock	55g ( all axes ) 100ms
Impact Shock	23g ( all axes ) 250ms
Pin Penetration	0.4cm2 pin 23kg, 1.5m
Alternative Electric Field ( AEF )	64kA 10MA/S 1m
Temperature Range	-40 – 75℃ ( Operation )
Temperature Range	-40 – 85℃ ( storage )
Standard	IEEE 1482.1 – 2013 CFR 49 Part 229 Appendix D Option A
