Original price was: $16.00.$13.00Current price is: $13.00.
Technical Specifications
| Model No | XD – C214 ( in-car monitoring ) |
| Imaging device | 1/2.9 1M Pixel CMOS |
| Pixels | 720P/1080P/25fps 720P/1080P/30fps |
| Video output | AHD 1.0Vp-p/75Ω |
| Minimum illumination | 0.001Lux while IR in operation |
| IR range | 3 – 6 m |
| SNR | >50dB |
| Lens | 2.8mm F2.0 |
| Lens angle | 950 H 600V |
| Electronic shutter | AUTO: 1/50sec 1/60sec |
| White balance | AUTO |
| Gamma correction | 0.45 |
| Image coloring | Color, Black and white while IR in operation |
| Mirror effect | available |
| Interface | 4-pin air connector |
| Cable length | 0.5m |
| Voltage | DC 9 – 16V |
| Current | 240mA@12V |
| Temperature range | -300 ～ 850 |
| Moisture | ≤95% |
| IP code | IP54 |
Description
Features
- mounted inside a vehicle for recording of real-time events
- 720P/1080P
- night vision effect with IR range of 3 – 6m
- IP rating: IP54
Vendor Information
- No ratings found yet!
-
Car Black Box with Embedded ADAS Solutions X505Versatile DVR with Rugged Memory Device
The car black box has 4 video channels for tracking and real-time detection of your car operation. The rugged fireproof memory device survives 1100℃ high intensity fire and enables you to access your data in harsh conditions like fire, water immersion or hard crash.
Face Identification
The system captures human faces and compares them against those that have been preserved in file to determine whether they match with each other. This helps to prevent unauthorized drivers from driving vehicles.
Front Vision Detection
To decrease avoidable crashes and to minimize accidents, the ADAS + system will notify you of a pedestrian or a cyclist in the danger zone and alert you of any possibly imminent crashes. When you are veering off the current travel lane without a lane change signal, it will trigger spoken warnings.
Blind Spot Monitoring
When you signal a turn and shift lanes, the blind spot monitoring system will alert you of a vehicle or other objects nearby but that may be out of your sight.
Driver Behavior Analysis
You will hear a warning whenever our system detects any of your behaviors that are deemed abnormal or unsafe such as talking on the phone, smoking, shielding a camera, fatigue, drowsiness, etc.
A Variety of Recommended Applications
We recommend the use of this intelligent car black box for fleet surveillance and management of public buses, school buses, oil tankers, coaches, vans or other commercial vehicles.
$490.00 -
Car Black Box / Mobile DVR N7Features:
- 8 x 720p/1080p video channels
- GPS + BDS dual positioning modules
- WiFi-AP 3G/4G LTE telecommunication
- CAN bus connection ( ignition, speed, brake, lights, motor rotations, fuel consumption, etc. )
- Dual SIM card slots
- With an optional external rugged data memory device that survives 11000C high temperature fire and functions 100m underwater for 240 hours
- For fleet tracking, monitoring and management online when connected to our platform, better performance and more functions if with our ADAS system
- Recommended for passenger buses, heavy duty trucks, oil tankers and other commercial vehicles.
- Size：200 x 200 x 70mm
- NWT：2000g
$428.00 -
Refractory Data Memory Module QM – C ModelFeatures:
A state-of-the-art fireproof model of memory
device for use in extremely harsh and tough
conditions
An embedded or peripheral refractory module
of data memories for trains or car recording
systems, bus monitors ( DVR ) or other security
products protecting your data in case of
emergency or in accidents
FPC connector that may be connected to USB
via an adaptor
Storage via eMMC or SSD that can be
converted into USB standard via an adapter
As refractory as a flight data recorder against
1100℃ high temperature fire
Survivable at 100m deep water for 240 hours
Shell made from 6mm alloy steel
As per international standard of railway
equipment ( on board driving data recording
system ): IEC62625.1 2013 with related thirdparty verifications and test reports
Size: 95 x 80 x 48 (mm)
NWT: 1.3kg$998.00 -
Car Black Box / Mobile DVR M505Features:
- High definition video channels
- GPS/BDS/GLONASS positioning modules
- 4G/ WiFi/Bluetooth wireless transmission
- Face identification ( optional )
- An optional peripheral rugged data memory device that survives 11000C high intensity fire and functions 100m underwater for 240 hours
- For tracking, surveillance and fleet management online when connected to our platform
- A telematics device for data protection of passenger buses, delivery trucks, oil tankers or other commercial vehicles.
- Size：160 x 140 x 48mm
- NWT：800g
$166.00 -
Front & Rear View Dual Lens Car Camera XD-C3T2Technical Specifications
Model No XD – C3T2 ( front and rear view ) Imaging device 1/2.9 1M Pixel CMOS Pixels 720P/1080P/25fps 720P/1080P/30fps Video output AHD 1.0Vp-p/75Ω Minimum illumination Front view: 0.01Lux In-car: 0lux ( IR open ) In-car: 0Lux with IR in operation
IR range 3 – 8 m SNR >50dB Lens Front view: 2.8mm@F2.0 In-car: 1.9mm@F2.0
Lens angle Front view: 1100 H /800V In-car: 1500 H /1000V
Electronic shutter AUTO: 1/50sec 1/60sec White balance AUTO Gamma correction 0.45 Image coloring Color, Black and white while IR in operation Mirror effect Available Interface 4-pin air connector Cable length 0.5m Voltage DC 9 – 14V Current 300mA@12V Temperature range -200 ～ 800 Moisture ≤95% IP code IP54 Original price was: $35.00.$29.00Current price is: $29.00. -
In-car Monitoring Dome Camera XD – C212Technical Specifications
Model No XD – C212 ( in-car monitoring ) Imaging device 1/2.9 1M Pixel CMOS Pixels 720P/1080P/25fps 720P/1080P/30fps Video output AHD 1.0Vp-p/75Ω Minimum illumination 0.01Lux while IR in operation IR range 3 – 6 m SNR >50dB Lens 2.8mm F2.0 Lens angle 950 H 600V Electronic shutter AUTO: 1/50sec 1/60sec White balance AUTO Gamma correction 0.45 Image coloring Color, Black and white while IR in operation Mirror effect Available Interface 4-pin air connector Cable length 0.5m Voltage DC 9 – 16V Current 240mA@12V Temperature range -300 ～ 850 Moisture ≤95% IP code IP54 Original price was: $17.00.$15.00Current price is: $15.00.
