Name: Reinforced Refractory Data Memory Module TR - P
SKU: 8553
Availability: InStock

true 30

$Reinforced Refractory Data Memory Module TR – P$

$2,009.05

Features

A crashworthy rugged data memory module engineered for protection of footage of security camera systems in extreme environments.
Tough housing made of alloy steel, compact design and easy to mount.
Stored data immediately accessible in case of harsh events such as fire, explosion, hard crash or water immersion.
Storage via eMMC.
Proof against 1100℃ high intensity fire.
Antishocking and waterproof
M12 5-pin air connector
An ideal black box for video protection in security surveillance systems of trains, oil tank trailers and heavy-duty trucks.
As per international railway equipment quality standard: IEC62625.1 2013
Size: 92 x 80 x 48mm
NWT: 1.3kg

[For further details click on the logo to visit manufacturer website Macfaith.com]

Description

Technical Specifications

Interface connection	Air connector with adaptor cables for SATA2.0, USB2.0, eMMC or NAND Flash
Storage Capacity	eMMC (TLC): □32G □64G □128G
Writing Circulation	3000 times
Fire Resistance	1100℃/ 15min, 950℃/ 20min,
Fire Resistance	650℃/ 30min followed by 300℃/ 60min followed by 100℃/ 300min
Water Immersion	100m deep water 240hours
Liquid Oil Immersion	48 hours
Hydrostatic Pressure	Salt water 3.5% —>48h, 1.5 bar ( 15m )
Magnetic Field	64kA/m increasing with 10 MA/s
Antiknock Quality	0.5ms Top Side: 1008KPa ( 1kgTNT/1m )
Static Extrusion Force	110KN 5min ( 3 axes )
Impact Force	55Gs ( 3 axes )/100ms
Pin Penetration	23kg, 6.4mm steel pin, 1.5m drop height, 3 main axes
Temperature Range	-40 ～ 75℃ ( operation )
Temperature Range	-40 ～ 85℃ ( storage )
Power	Input: 5V±5% Consumption: <0.5W
Standard	IEC 62625.1 – 2013 TJJW024-2014
