$215.05
FeaturesÂ
- An intelligent security video recorder for real-time tracking and detection of passenger buses, school buses, delivery trucks, etc.Â
- DVR with embedded ADAS & DMS softwareÂ
- High definition ( AHD ) video channelsÂ
- Infrared night vision cameras may be connectedÂ
- Intercom system for communication between the DVR and the platformÂ
- Watchdog to boot automotive applications whenever detecting software errors or hardware failures Â
- Delayed shutdown of video recording for up to 24 hours
- Scheduled video recording supported
- Power-off protection to prevent data loss Â
- M12 air connector adoptedÂ
- GPS + BDS dual positioning modules  Â
- 3G/4G & WiFi LTE telecommunicationÂ
- G-Sensor, RJ45 and RS232 available for your optionÂ
Description
AI Functions Â
 Advanced Driver Assistance System ( ADAS ) Â
To decrease avoidable crashes and to minimize accidents, the embedded ADAS system send warnings or alerts whenever it detects an impending collision in the front or when pedestrians or motor vehicles are coming nearby beside your vehicle within the short distance as defined by DVR settings.Â
The system alerts the driver when your vehicle deviates from the current travel lane without a lane change signal.Â
An occlusion alarm will be triggered when any of your car cameras is blocked in part or in whole. Â
Driver Monitoring System ( DMS )Â Â
The system aims to elevate the driver’s awareness and alert him of signs of drowsiness ( yawning, blinking or closing eyes ) and distraction ( smoking, making calls ) while steering a vehicle on the way. An alarm will be signaled when the driver disappears from the camera vision. The DMS helps reduce accidents and improve driver’s safety.   Â
Â
Technical Specifications
| System | Linux  |
| Languages | Chinese, English, etc. |
| Login Safety | Password for login by both user and administrator |
| Video Input | 4/8 CH AHD 1080P, 720P, D1, HD1, CIFÂ Â |
| Image Compression | H.264/H.265   |
| Video Output | 1CH VGA Â 1CH air connector interface |
| Audio  | 4 CH input  4 CH output  |
| Image Display   | 1 – 4 images     |
| OSD Overlay | Channel, time, record, resolution, VIN, GPS, etc. |
| Wireless Communication | 4G, WiFi ( optional )  |
| Satellite Positioning  | GPS/BDS ( optional )     |
| Storage  | SD cards ( max 512G ) x 2   |
| G-Sensor ( optional ) | 3-axis accelerometer and 6-axis gyroscope |
| I/O Alarm | 10 CH input |
| Interfaces | USB 2.0 x 1   Â
1 x RJ45/RS232 available for option on the rear panel    |
| Power Input | DC 10～36V     |
| Power Consumption | ≤10W  |
| Temperature Range | -20～70℃ ( operation ) – |
| Operating Humidity | 20%～80%  |
| Dimensions | 133 x 128 x 42mm ( D/W/H )Â Â Â Â |
